TIP142 Equivalent

This is a replacement table for the tip142 equivalent. They both amplify circuits or act as switches.

Картина	Имя	Makers	Maximum Power	Maximum Current	Maximum Voltage	Тип упаковки
	ТИП142	ON Semiconductor	80W	10A	100В	ТО-220
	ТИП32С	ON Semiconductor	40W	3А	100В	ТО-220
	S8550	Санкен	15W	1,5А	50В	TO-92
	БД139	STMicroelectronics	12W	1,5А	80В	TO-3
	2N5401	ON Semiconductor	80W	10A	150V	ТО-220
	MJE2955T	ON Semiconductor	115W	15А	60V	ТО-220

Note:

In this table, 2N5041 is the most suitable substitute, and its parameters are fully compatible with TIP142. When using MJE2955T as a replacement, it should be noted that the voltage should not exceed the maximum voltage of MJE2955T, 60 V. When using S8550, BD139 as a replacement, it is necessary to see whether the voltage, current and power in the actual circuit are greater than the maximum parameter, and when replacing it with TIP32C, it is not possible to look at the parameter only, because TIP32 is a PNP transistor, and the polarity is different from that of TIP142, so it is necessary to modify the circuit before replacing it.
