NJW0281G Equivalent

NJW0281G：NJW0281G is an NPN bipolar power transistor that can be widely used in high-fidelity audio amplifiers, industrial equipment, and signal processing applications. It has a collector-emitter breakdown voltage of 250V (BVceo), a maximum collector current of 15A, and a collector saturation voltage of 1V (at 500mA/5A). It is commonly paired with NJW0302G (a PNP complementary transistor) to form a push-pull circuit, with gain matching precision within 10%. It is recommended to configure overcurrent and overvoltage protection to prevent damage from abnormal operating conditions.

Picture	Product Model	Type	VCEO (V)	IC (A)	PD (W)	Package
	NJW0281G	NPN	250	15	150	TO-3P
	MJ15024G	NPN	250	16	250	TO-3P
	2SC5200	NPN	230	15	150	TO-3P
	TTC5200	NPN	230	15	150	TO-3PL
	2N3055	NPN	60	15	115	TO-3
	TTA5200	NPN	230	15	150	TO-3P
