KBPC5010 Bridge Rectifier | Datasheet, Pinout, Wiring Diagram & Specifications
Explore the KBPC5010 bridge rectifier for reliable performance in single-phase systems. Access the Reference manual for detailed information on wiring diagrams, pinout, and the 50A 1000V metal case design. Get insights into KBPC5010 applications and connections, including schematic and diode specifications.
- Brands: MDD
- Mfr.Part #: KBPC5010
- Datasheet: KBPC5010 Datasheet PDF
- Package: 4-Square, KBPC
- Series: KBPC
- In Stock: 900
- Voltage-PeakReverse(Max): 1 kV
- Current-AverageRectified(Io): 50 A
- Voltage-Forward(Vf)(Max)@If: 1.1 V @ 25 A
- Current-ReverseLeakage@Vr: 10 µA @ 1000 V
- Operating Temperature: -50°C ~ 150°C (TJ)
- Price: inquiry
