2N3904
2N3904

2N3904 | datasheet | pinout | transistor onsemi

Discover the 2N3904 NPN transistor, ideal for applications like signal inverter and amplifiers. Access its Reference manual, spec sheet, and SPICE model for detailed technical insights. Compare it with 2N2222 and explore its pinout, transistor circuit options, and alternative models.
Brands: onsemi
Download: 2N3904 Datasheet PDF
Price: inquiry
In Stock: 15,199
Transistor Type: NPN
Current-Collector(Ic)(Max): 200 mA
Voltage-Collector Emitter Breakdown (Max): 40 V
Package: TO-226-3, TO-92-3 (TO-226AA)
send your inquiry
