IR2130S application note & impact wrench | circuit
- 駆動構成: Half-Bridge
- チャンネルタイプ: 3-Phase
- ゲートタイプ: IGBT, N-Channel MOSFET
- パッケージ: 28-SOIC (0.295, 7.50mm Width)

HK$250.00以上のご注文で送料無料

迅速な対応、迅速な見積もり

すぐに発送、アフターサービスも安心

オリジナルチャネル、本物の製品の保証
IR2130 Pinout Equivalent
1:Overview of the IR2130:
The IR2130 is a high-voltage gate driver chip produced by Infineon, designed for MOSFET and IGBT power devices. It can be widely used in motor control, industrial inverters, and power systems. It supports up to 600V power drive, with a forward peak of 250mA (HIN pin) and a reverse peak of 500mA (LIN pin). This device is capable of fast switching and includes built-in overcurrent protection and undervoltage lockout features.
2:IR2130 Important pin function definition:
ピン番号 | ピン名 | 説明 |
---|---|---|
Pin1 | VCC | Low side and logic fixed supply |
Pin2, 3, 4 | HIN1,2,3 | Logic inputs for high side gate driver outputs (HO1,2,3), out of phase |
Pin5, 6, 7 | LIN1,2,3 | Logic inputs for low side gate driver output (LO1,2,3), out of phase |
Pin8 | FAULT | Indicates over-current or undervoltage lockout (low side) has occurred, negative logic |
Pin9 | ITRIP | Input for over-current shutdown |
Pin10 | CAO | Output of current amplifier |
Pin11 | CA- | Negative input of current amplifier |
Pin12 | VSS | Logic ground |
Pin28, 24, 20 | VB1,2,3 | High side floating supplies |
Pin27, 23, 20 | HO1,2,3 | High side gate drive outputs |
Pin26, 22, 18 | VS1,2,3 | High side floating supply returns |
Pin16, 15, 14 | LO1,2,3 | Low side gate drive outputs |
Pin13 | VS0 | Low side return and positive input of current amplifier |
3:Alternative model recommendation
A6862:A6862 features dual-channel drive capability, enabling it to control two independent DC motors or one bipolar stepper motor simultaneously.Each channel can output a large current to meet the power requirements for normal motor operation. The ability to provide high current output means it can drive motors with relatively higher power, ensuring that the motor generates sufficient torque for quick start-up, stoppage, and precise speed control.
FD6288Q:FD6288Q features a unique dual H-bridge drive architecture, allowing it to simultaneously drive two DC motors or a single bipolar stepper motor. Independent control of the two H-bridges enables flexible forward and reverse motor operation, providing robust support for complex motor control requirements. Whether you need two motors to run synchronously or asynchronously, FD6288Q handles it effortlessly.
U5316:U5316 is a three-phase full-bridge driver chip introduced by Uni-Semiconductor, primarily used for driving three-phase motors such as AC induction motors and brushless DC motors. It is widely applied in industrial control, home appliances, and electric tools.U5316 is a high-performance three-phase full-bridge driver chip that, with its high voltage support, multiple protection mechanisms, and compact packaging, has wide applications in industrial control, home appliances, and electric tools.
G2061:G2061 adopts three-phase full-bridge topology structure. It has six independent gate drive channels built in and can directly drive the six power switching transistors (such as MOSFET or IGBT) of a three-phase motor. By controlling the on and off of different bridge arms, functions such as forward and reverse rotation and speed regulation of the motor can be realized. It is suitable for three-phase motor systems that require high-precision control.
4:Comparison of main parameters for several models
Chip Model | Supply Voltage Range | Continuous Output Current | パッケージタイプ | Protection Features |
---|---|---|---|---|
IR2130 | 12–600V DC | 2A per channel | SOIC-14 | Over-current, Over-voltage, Under-voltage, Thermal |
A6862 | 5.5–40V DC | 2.5A per channel | SOIC-16 | Over-current, Thermal, Short-circuit |
FD6288Q | 5–25V DC | 2A per channel | SOP-8 | Over-current, Thermal, Under-voltage |
U5316 | 280V DC Bus | 1.5A/1.8A (source/sink) | TSSOP20 | Over-current, Thermal, Under-voltage |
G2061 | 250V DC Bus | 1.5A/1.8A (source/sink) | QFN24 | Over-current, Thermal, Under-voltage, Dead-time |
